Result of the researchers’ evaluation according to UD requirements
The researcher evaluation results showed that building A “The Local Unit of Aswan City” obtained 46.76% of compliance to UD requirements, while the total percentage of their compliance to UD requirements was 50.93% for building B “Aswan University administrative building”. Building C “The National Organization for Social Insurance—Government Sector” obtained 44.44% of compliance with UD requirements. In a more detailed analysis, the percentage of the UD requirements for each design element is shown by the ratios in Figs. 20, 21, and 22.
Based on the abovementioned detailed percentage, the study observed that “Using Circulation systems” in building B achieved the highest percentage (61.67%) than building C (50.00%) and building A (48.33%) as illustrated in Fig. 23. The absence of elevators in building A has an effective role in the building score. More detailed analysis showed that the item “Hallways and Corridors” in buildings A and B were equal with 55.56%, while “Mechanical Circulation Systems” (Elevators) was the lowest item with 33.33% in building A. Regarding the “Ramps and Stairs” item, the ratios were close to each other in the three buildings as illustrated in Fig. 24.
The design element “Entering and Exiting” and its items were equal in buildings A and B by 52.94% as shown in Fig. 23; “Departing the Entrance and Exit Area” item achieved the percentage of 46.67% in the three buildings due to the absence of multiple physical signs which participate in recognizing the building outlets. Regarding the “Identifying the entrance and exit” and “Maneuvering through the Entrance or Exit” items, the ratios were equal in buildings A and B with 55.56% for both, and 33.33%, 44.44% in building C, as illustrated in Fig. 24).
The study result showed that the “Wayfinding” element was equal in buildings A and C and obtained 42.86% even though, building B ratio was 43.81% as illustrated in Fig. 23. The Convergence of “Wayfinding” ratios, in the three buildings is due to the absence of a clear information system design in all of them. In detail, the research showed that the item “Paths/ Circulation” in building B achieved the highest percentage of 72.22% than buildings B and C, while the items “Information System Design”, “Sign Content” and Orientation Aids were equal in the three buildings as illustrated in Fig. 24.
It is clear from the previous ratios that building “C” has the least compliance with UD requirements, despite the fact that it is the most recent of them in terms of construction and provides its services to elderly users. And after analyzing the previous results, it became clear that there were no tactile, sound, and visual indicators in any element of the study buildings. The absence of ramps limits accessibility to the entrances in all case study buildings, even the newly constructed ones. Corridors have a very appropriate width in old study buildings, but the misuse reduces the efficiency of their performance. In the newly constructed building, the small widths of the corridors impede access to rooms for those in the sitting position. The omission of the Information System Design in all study buildings limits the accessibility within the buildings.
Result of the users’ evaluation according to UD principals
Regarding building A, the users’ evaluation results revealed that the UD principles (simple and intuitive use, and low physical effort) achieved the highest percentage 42% and 43%, respectively, though their “relative weights” were 11.12%, which referred to their middle importance. Also, the principle “perceptible information” achieved the lowest ratio of 17% that is compatible with its relative weight of 7.9% as shown in Fig. 25.
It is clear that Building A has no “Elevator”, and the results showed that “Stairs” achieved the highest percentage in compliance with each UD principle, although, “Wayfinding” obtained the lowest percentage with each UD principle as, there is no “Wayfinding” system, as in Fig. 26.
With respect to building B, the highest percentage was achieved by principles (simple and intuitive use, and low physical effort) 33% and 30%, respectively. For Size and space for approach and use principles, the results affirmed that its ratio was 24%, despite its relative weight was 25.26%, which referred to its highest significance, as presented in Fig. 27.
The “elevators” attained a low percentage in compliance with UD principles. “Stairs” and “Corridors” accomplished convergent percentages with each UD principle. Also, “Entering and exit” obtained a decreased percentage with UD principles excluding “Simple and intuitive use” and “Size and space for approach and use” as displayed in Fig. 28.
Concerning building C, the users’ results displayed that the principles “Size and Space for Approach and Use” and “Perceptible Information” achieved the decreased percentage of 18% and 17%, respectively. Though “Perceptible Information principle” has the lowest relative weight of 7.91%; nevertheless, “Size and Space for Approach and Use principle” attained the highest relative weight of 25.26%. It is obvious that “Equitable Use principle” had the middle significance with a relative weight of 14.34% and obtained 28% of compliance of UD principles, as shown in Fig. 29.
“Elevators” accomplished 56% in compliance with the UD principles. Even though, “Stairs”, “Corridors”, and “Entrances and exits” achieved convergent percentage with all principles of UD except the stairs with “Simple and Intuitive Use” obtain the highest percentage of 65%. Thus, “Wayfinding” obtained the lowest percentage with all UD principles excluding “Tolerance for Error principle”, as shown in Fig. 30.
Ultimately, it is apparent in the three case study buildings, that Perceptible Information principle is the most absent and not applied one, while, Simple and Intuitive Use principle is the most existing and applied one
